Measurement
system |
Switchable between two- and three- electrode
methods |
Measurement
range |
20 ohms (0 to 20.00 ohms) |
200 ohms (0 to 200.0 ohms) |
2000 ohms (0 to 2000 ohms) |
Accuracy |
+/-1.5 %rdg. +/-8 dgt. |
+/-1.5 %rdg. +/-4 dgt. |
+/-1.5 %rdg. +/-4 dgt. |
Earth voltage |
0 to 30.0
Vrms, Accuracy: +/-2.3 %rdg. +/-8 dgt. (50/60 Hz), +/-1.3 %rdg. +/-4 dgt. (DC) |
Dustproof and
waterproof |
IP65/IP67 (EN60529) |
|
|
Power supply |
LR6 Alkaline
battery x4 |
Possible number of measurements: 100 times |
(measurement conditions: three-electrode method, measuring 10
ohms) |
Dimensions and mass |
185
mm (7.28 in)W x 111 mm (4.37 in)H x 44 mm (1.73 in)D, 570 g (20.1 oz) |
(including
protector and batteries) |
|
Accessories |
Auxiliary
earthing rod L9840 (2 piece set) x1, Measurement cable (black 4 m) L9841 |
x1, Measurement cable (yellow 10 m, equipped with winder)
L9842-11 x1, |
Measurement cable (red 20 m, equipped with winder) L9842-22
x1, Carrying case |
C0106 x1, Protector x1, LR6 Alkaline battery
x4, Instruction manual x1 |
Varilla auxiliar de puesta a tierra L9840 (set de 2 piezas) x1 Cable de medición (negro 4 m) L9841 x1 Cable de medición (amarillo 10 m, equipado con bobinadora) L9842-11 x1 Cable de medición (rojo 20 m, equipado con bobinadora) L9842-22 x1 Maleta de transporte CO106 x1 Protector x1 Batería Alcalina LR6 x4 Manual de Instrucciones x1
|
|
|
|
|
|
|
|
|
